S5 - interface cable

With each interface of your PC to the S5-PLC

• multifunctional, several functions in one product
• well-priced alternative to high-priced original products

application table:
PG-UNI + PG-UNI-II
S5-LAN
PG-USB
PG-COM
PG-ISO-SET
device type
S5-90U
x
+ext. 24V
x
x
x
S5-95U
x
+ext. 24V
x
x
x
S5-100U
x
+ext. 24V(2)
x
x
x
S5-115U
at 944 + 9359-8
at 944 + 9359-8 + ext. 24V
x
x
x
S5-135U
x
x
x
x
x
S5-155U
x
x
x
x
x
S5-AG110S
+9359-5-150 + 9359-4
+9359-5-150 + 9359-4 + ext. 24V
+9359-5-150-USB
+9359-5-150 + 9359-4(1)
S5-AG130W/B
+9359-5-150 + 9359-4
+9359-5-150 + 9359-4 + ext. 24V
+9359-5-150-USB
+9359-5-150 + 9359-4(1)
S5-AG150A/K/S/U
+9359-5-150 + 9359-4
+9359-5-150 + 9359-4 + ext. 24V
+9359-5-150-USB
+9359-5-150 + 9359-4(1)
CP-143
x
x
x
CP-521
+CP521 adapter

+CP521 adapter(1)
CP-523
+CP523 adapter

+CP523 adapter(1)
CP-525
+9359-5

+9359-USB

+9359-5(1)
CP-526
x

x

x
CP-527
x

x

x
CP-528
x

x

x
CP-544
x

x

x
CP-5430
x

x

x
CP-5431
x


IP-252
x

x

x
IP-247
x

x

x
IP-252
x

x

x
IP-266
+9359-4
x
+9359-4(1)
WF-470
+9359-4 + 9359-5-WF470
+9359-5-WF470-USB
+9359-5-WF470 + 9359-4(1)
SIN-805
+9359-6
+9359-6 + ext. 24V
+9359-6-USB
+9359-6(1)
SIN-820
+9359-6
+9359-6 + ext. 24V
+9359-6-USB
+9359-6(1)
SIN-840
+9359-6
+9359-6 + ext. 24V
+9359-6-USB
+9359-6(1)
SIN-850
+9359-6
+9359-6 + ext. 24V
+9359-6-USB
+9359-6(1)
SIN-880
+9359-6
+9359-6 + ext. 24V
+9359-6-USB

+9359-6(1)
max. prolongation: 300m (UNI-extension) 300m (S5-LAN-extension) +ext. 24V 100m (PG-USB-extension)   300m (UNI-extension)

(1) ISO adapter can not be used because the required supply voltage on the PG interface of the module is not present.
(2) At the CPU 6ES5 102-8MA02 Release 3 is a PG-ISO-Adapter or Netz-Adapter additional required.



Shop:S5-LAN++ - Process Informatik Entwicklungsgesellschaft mbH

S5-LAN++

Industrial Ethernet - TCP/IP for all SIMATIC-S5 via the programming-interface

• fastest installation to the network of every SIMATIC - S5
• reading and writing of S5-data (E,A,M,DB,Z,T) via TCP/IP
• ideal for process-visualisation
• programming with STEP 5 via Ethernet
• simultaneous programming and visualisation possible (integrated multiplexer function)
• power supply from the S5-PLC or external
• disclosed TCP/IP-protocol
• DHCP / Auto-IP supported
• timing-equitable communication with the S5-PLC via integrated firmware
• driver-DLL for Windows available, EXCEL and WORD can read/write S5-data
• compatible with VIPA-S5-TCP/IP driver
• direct operation with WinCC via TCP/IP driver S5 Layer4 possible
• with WinCC Flexible (e.g. MP377, TP177B) via S7-TCP/IP to the Simatic S5 (CP-343-1 compatible)
• data exchange between S5 – S5 and S5 - S7 via TCP/IP
• RK 512 and TCP/IP H1-ISO-On-TCP RFC1006 (CP1430 TCP) supported
• versions: 3964R-LAN, ASCII-LAN, PG-LAN, as RS232-version and for the MUX757
Technical Specifications:
Supply voltage: 24V/DC +/- 20%
Power consumption: 2 watt
Display: status-LED
Handling/Configuration: reset-switch-key (factory setting)
S5-LAN Manager
Interfaces:
to the PLC:
TTY/20mA current loop (S5-LAN passiv, PLC aktiv)
to the PD/PC:
10/100BaseTX RJ45-ethernet jack
Operating temperature: 5 - 55°C
Case: ABS-plastic case
Dimensions: 42 x 15 x 65 mm


Programming of S5-PLC’s via LAN

Unbenanntes Dokument
You would like to respond to your S5-PLC via LAN, but not integrate an Ethernet-CP? No problem, plug the S5-LAN++ on the PD-interface and access via LAN.
Communication with Win98 – XP/Vista via LAN to S5-PLC

Unbenanntes Dokument
You still have a PC with Win98 and Step5-package and would like to go Online on your S5-PLC via LAN? No problem, the provided virtual Com-Port PLCVCom emulates a COM-port on your PC with which you go Online. Even your MS-DOS-based Step5-software can use this virtual Com-Port. With a patchtool for the Siemens Step5-software, which is provided as well, nothing else stands in your way to communicate via LAN.
Watching of S5-PLC’s via LAN without Ethernet-CP

Unbenanntes Dokument
Your panel only has a LAN-socket as PLC-interface, no problem. Connect this socket with the S5-LAN++ and plug it directly on the PD-interface of the PLC. Then access to the variables and data of the PLC is already available.
Watching of S5- PLC’s with panel for S7-PLC

Unbenanntes Dokument
Your panel only has a LAN-socket as PLC-interface and supports only S7-RFC1006, no problem. Connect this socket with the S5-LAN++ and plug it directly on the PD-interface of the PLC. The S5-LAN++ performs adverse your panel as a S7-PLC although you receive the data from the S5-PLC. Then access to the variables and data of the S5-PLC is already available.
Remote maintenance of your S5-PLC via LAN / Internet

Unbenanntes Dokument
You have access to a on-site network and your PLC has no LAN-connection? No problem, plug the S5-LAN on the PLC and you will have immediate access to the PLC from afar.
PLC coupling (data exchange between PLC’s)

Unbenanntes Dokument
Your pumping stations report the water levels of the central control via telephone network. The central office itself can of course transmit commands/messages to the substations as well. Therefore no dedicated line is required, it’s sufficient when the stations connect via network (DSL-router).
Visualisation via 3964R-interface without using the protocol itself

Unbenanntes Dokument
Your visualisation-software does not support a 3964R-protocol, but you have to apply this package? No problem, connect the 3964R-LAN to your CP and activate the RFC1006-emulation in the module. Now your software gets the data from the module via RFC1006, which in turn communicates with the assembly via 3964R.
Extension of a 3964R-line via LAN

Unbenanntes Dokument
There is a control with CP524 in your outstation and the communication partner of the CP has moved locally. Connecting path is a LAN-network. So each of both participants gets a 3964R-LAN and after input of the partner’s IP-address a coupling via LAN will be configured.
article:
Art. ID.nameprice
9359-LAN S5-LAN++ 390,- €

variant:
Art. ID.nameprice
9359-RK S5-3964R-LAN 749,- €
9359-RK-RS S5-3964R-LAN RS232-version 839,- €
9359-ASCII S5-ASCII-LAN 490,- €
9359-LAN-RS S5-LAN++ RS232-version 480,- €
9359-LAN-M S5-LAN-MUX757
S5-LAN with path selection (MUX757)		 1890,- €
9359-PG-LAN S5-PG-LAN 799,- €

accessories:
Art. ID.nameprice
9391.1 24V DC power-supply unit 625mA
Primary 110V - 240 VAC Euro+USA-plug		 39,- €
9359-5-150 AG-150-adapter
for PG-UNI + PG-UNI-II-cable to AG-150		 39,- €
9636-CROSS Cross-cable 3m Cat5+
both sides RJ45-Plug		 10,- €
9359-4 NETZ-adapter
for PG-UNI-cable /UNI-II-cable/S5-LAN		 59,- €
9636-TCPIP Patch-cable 3m, Cat5+
both sides RJ45-Plug		 10,- €
9359-8 PG-ISO-adapter
1000V galv. seperation		 89,- €
9359-6 SINUM-adapter
for PG-UNI + PG-UNI-II-cable to SINUMERIK		 39,- €
9352-24 Power connector 2pins small 2,- €

Shop:PG-USB - Process Informatik Entwicklungsgesellschaft mbH

PG-USB

Coupling of PC (USB-port type A) with the 15pin X4/X5 PD-port of the PLC

• complete electronics in the plug housing
• slide lock for firm grip on the PLC
• power supply from the USB-port
• prolongable up to 100m on the PLC side
• runs with the standard S5-software despite virtual com-port (driver for Win2000 and XP will be provided)
Technical Specifications:
Supply voltage: 5V/DC
Power consumption: 0,3 watt
Display: 2 status-LEDs for RXT/TXD
Interfaces:
to the PLC:
TTY/20mA current loop (PG-USB aktiv, PLC passiv)
to the PD/PC:
USB 1.1 cable type A
Operating temperature: 5 - 55°C
Case: metal case
Dimensions: 50 x 40 x 17 mm


Active on every S5-PLC

Unbenanntes Dokument
You have to program an assembly which does not provide neither power sources nor voltages at your PD-interface, such as the AS511-card for example? No problem, the PG-USB-cable supplies itself completely from the USB-port and so it’s active adverse the communication partner. He uses own power sources for the communication.
Communication with Win98 – XP/Vista via USB to S5-PLC

Unbenanntes Dokument
You still have a PC with Win98 and Step5-package and would like to go Online on your S5-PLC via USB? No problem, the provided virtual Com-Port PLCVCom emulates a COM-port on your PC with which you go Online. With a patchtool for the Siemens Step5-software, which is provided as well, nothing else stands in your way to communicate via LAN.
article:
Art. ID.nameprice
9359-1 PG-USB-cable 3m
125,- €
9359-1.05M PG-USB-cable 5m
150,- €

accessories:
Art. ID.nameprice
9359-5-150-USB PG-USB AG-150-adapter
for PG-USB-cable to AG-150		 39,- €
9359-5-USB PG-USB CP-525-adapter
for PG-USB-cable to CP-525		 39,- €
9359-5K-USB PG-USB CP-525-K-adapter
for PG-USB-cable to CP-525-communication		 39,- €
9359-6-USB PG-USB SINUM-adapter
for PG-USB-cable to SINUMERIK		 39,- €
9359-5-WF470-USB PG-USB WF-470-adapter
for PG-USB-cable to WF470		 39,- €
9359-7-USB PG-USB-lengthening set
complete mounting set		 29,- €

Shop:S5toMPI - Process Informatik Entwicklungsgesellschaft mbH

S5toMPI

Connects the S5-PLC with a S7-PLC

• bi-directional exchange of data blocks
• automatic protocol- and baud rate detection
• power supply from the S7-PLC or external
• galvanic separation 1000V
• double-sided connected cable
• short plug to PLC
• firmwareupdate via internet for free
• easy handling without programming the S5/S7
• incl. 9 pol. adapter for connecting a S5-interface cable
• optional is a PG-COM or PG-UNI cable necessary
Technical Specifications:
Supply voltage: 24V/DC +/- 20%
Power consumption: 2,5 watt
Display: double lined LCD-display
Handling/Configuration: Kabelmanager-Software
keypad on the back
Interfaces:
to the PLC:
PPI/MPI/Profibus interface: 9,6 KBd - 12 MBd
to the PD/PC:
RS232: 9,6 KBd - 115,2 KBd
USB 1.1 for cable type A <-> A
Operating temperature: 5 - 55°C
Case: ABS-plastic case
Dimensions: 146 x 41 x 29 mm


Coupling of S5-PLC with S7-PLC via PD-interfaces

Unbenanntes Dokument
You still have an installation in your machinery which is equiped with a S5-PLC and the modification to S7 isn’t profitable, but the central control needs the manufacturing data? No problem, connect the S5-PLC via the S5toMPI to your central control and the S5toMPI ensures that the data will be accordingly interchanged. Both sides can be active, but also only one. Both is configurable.
article:
Art. ID.nameprice
9352-S5-OP S5toMPI/Profibus 399,- €

accessories:
Art. ID.nameprice
9391.1 24V DC power-supply unit 625mA
Primary 110V - 240 VAC Euro+USA-plug		 39,- €
9350-9-CHP CheapConn Busconnector
for PROFIBUS		 25,- €
9391-HH DIN-rail-holder for MPI/PPI 10,- €
9350-9-CHP-CC Option CheapConn for MPI
9350-9-CHP+9350-9-CHP-K already mounted		 35,- €
9352-24 Power connector 2pins small 2,- €
9350-9-CHP-K Connecting cable MPIx to CheapConn 5,- €
9350-WAND Wall-mounting
for MPI/PPI + MPI-II + MPI-USB		 5,- €

appropriate interface-cables:
Art. ID.nameprice
9359.10CM PG-COM-cable 0.1m special length 59,- €
9359 PG-COM-cable 3m 59,- €
9359.05M PG-COM-cable 5m 66,- €
9359.10M PG-COM-cable 10m 83,- €
9359.15M PG-COM-cable 15m 97,- €
9359-2 PG-UNI-II-cable 3m
for PLC's/CP's+ LED + metal case		 99,- €
9359-2.05M PG-UNI-II-cable 5m
for PLC's/CP's+ LED + metal case		 109,- €
9359-2.10M PG-UNI-II-cable 10m
for PLC's/CP's+ LED + metal case		 125,- €
9359-3.10CM PG-UNI-cable 0.1m special length
for PLC's and CP's 		89,- €
9359-3 PG-UNI-cable 3m
for PLC's and CP's 		89,- €
9359-3.05M PG-UNI-cable 5m
for PLC's and CP's		 99,- €
9359-3.10M PG-UNI-cable 10m
for PLC's and CP's		 115,- €

Shop:PG-COM - Process Informatik Entwicklungsgesellschaft mbH

PG-COM

Couples the PC (9 pol. COM-interface) with the 15 pol. X4/X5 interface port of the PLC

• complete electronics in the plug housing
• slide lock for firm grip on the PLC
• supply from the PLC over the 5V DC of the PD-port
Technical Specifications:
Supply voltage: 5V/DC
Power consumption: 0,2 watt
Display: -
Interfaces:
to the PLC:
TTY/20mA current loop (PG-COM passiv, PLC aktiv)
to the PD/PC:
RS232: 9,6 KBd - 115,2 KBd
Operating temperature: 5 - 55°C
Case: plastic case
Dimensions: 47 x 40 x 15 mm


Serial communication to the S5-PLC (CPU-assemblies 15pin)

Unbenanntes Dokument
You have a PC with programming software and a 9pin COM-port as interface? No problem, for this purpose the PG-COM-cable is exactly the right product. Connect it to PLC and PC and you’re Online.
article:
Art. ID.nameprice
9359.10CM PG-COM-cable 0.1m special length 59,- €
9359 PG-COM-cable 3m 59,- €
9359.05M PG-COM-cable 5m 66,- €
9359.10M PG-COM-cable 10m 83,- €
9359.15M PG-COM-cable 15m 97,- €

variant:
Art. ID.nameprice
9359-SON Additional charge for special wiring
PG-COM/ PG-UNI/ PG-UNI-II		 5,- €
9390 Additional charge for special length
for S5-Interface cables per Meter 3,- Euro		 3,- €
9359.X Special length: PG-COM-cable (3m) + 9390 69,- €

Shop:PG-UNI - Process Informatik Entwicklungsgesellschaft mbH

PG-UNI

Couples the PC (9 pol. COM-interface) with the 15 pol. X4/X5 interface port of the PLC

• complete electronics in the plug housing
• slide lock for firm grip on the PLC
• supply from the PLC of 20mA-current sources
• galvanic separation to 1000V with PG-ISO-adapter
• prolongable up to 300 meters on PLC side
• functioned also at many CP’s, IP’s and Sinumerik-PLC’s
Technical Specifications:
Supply voltage: from the current sources of the PLC
Power consumption: 0,2 watt
Display: -
Interfaces:
to the PLC:
TTY/20mA current loop (PG-COM passiv, PLC aktiv)
to the PD/PC:
RS232: 9,6 KBd - 115,2 KBd
Operating temperature: 5 - 55°C
Case: plastic case
Dimensions: 47 x 40 x 15 mm


Serial communication to the S5-PLC

Unbenanntes Dokument
You have a PC with programming software and a 9pin COM-port as interface? No problem, for this purpose the PG-UNI-cable is exactly the right product. Connect it to PLC and PC and you’re Online. Even the 25pin interface of the AS511-card is no problem. You need the NETZ-adapter and also the AG-150-adapter and then this control is programmable, too.
Serial communication with CP and more S5-assemblies

Unbenanntes Dokument
You have a PC with programming software and a 9pin COM-port as interface? No problem, for this purpose the PG-UNI-cable is exactly the right product. Connect it to a Siemens assembly such as H1-CP (CP1430), WF470 and PC or CP-525 with the CP525-adapter and PC and you’re Online.
article:
Art. ID.nameprice
9359-3.10CM PG-UNI-cable 0.1m special length
for PLC's and CP's 		89,- €
9359-3 PG-UNI-cable 3m
for PLC's and CP's 		89,- €
9359-3.05M PG-UNI-cable 5m
for PLC's and CP's		 99,- €
9359-3.10M PG-UNI-cable 10m
for PLC's and CP's		 115,- €

variant:
Art. ID.nameprice
9359-SON Additional charge for special wiring
PG-COM/ PG-UNI/ PG-UNI-II		 5,- €
9390 Additional charge for special length
for S5-Interface cables per Meter 3,- Euro		 3,- €
9359-3.X Special length: PG-UNI-cable (3m) + 9390 101,- €

accessories:
Art. ID.nameprice
9359-9.M Adapter COM 1 : COM2
25pins (male) - 9pins (female)		 17,- €
9359-9 Adapter COM 1 : COM2
9pins (male) - 25pins (female)		 17,- €
9359-5-150 AG-150-adapter
for PG-UNI + PG-UNI-II-cable to AG-150		 39,- €
9359-5 CP-525-adapter
for PG-UNI + PG-UNI-II-cable <-> CP-525		 39,- €
9359-5K CP-525-K-adapter
for PG-UNI + PG-UNI-II-cable <-> CP-525-communication		 39,- €
9359-4 NETZ-adapter
for PG-UNI-cable /UNI-II-cable/S5-LAN		 59,- €
9359-8 PG-ISO-adapter
1000V galv. seperation		 89,- €
9359-7 PG-UNI - lengthening set
16,- €
9359-MAX233 RS232 / V24 chip
for interfacecable		 5,- €
9359-6 SINUM-adapter
for PG-UNI + PG-UNI-II-cable to SINUMERIK		 39,- €
9359-5-WF470 WF-470-adapter
for PG-UNI + PG-UNI-II-cable to WF470		 39,- €
9310 Additional charge 25-pins PC-plug 10,- €

Shop:PG-UNI II - Process Informatik Entwicklungsgesellschaft mbH

PG-UNI II

Couples the PC (9 pol. COM-interface) with the 15 pol. X4/X5 interface port of the PLC

• complete electronics in the plug housing
• slide lock for firm grip on the PLC
• supply from the PLC of 20mA-current sources
• galvanic separation to 1000V with PG-ISO-adapter
• prolongable up to 300 meters on PLC side
• functioned also at many CP’s, IP’s and Sinumerik-PLC’s
• ESD firm transducer component up to 15kV
• Display of RxD/TxD with LEDs
Technical Specifications:
Supply voltage: from the current sources of the PLC
Power consumption: 0,25 watt
Display: 2 status-LEDs for RXT/TXD
Interfaces:
to the PLC:
TTY/20mA current loop (PG-COM passiv, PLC aktiv)
to the PD/PC:
RS232: 9,6 KBd - 115,2 KBd
Operating temperature: 5 - 55°C
Case: metal case
Dimensions: 50 x 40 x 17 mm


Insensible communication with the S5-PLC

Unbenanntes Dokument

You need a communication to a PLC-device, which is stable against influence from out like frequency converter or electrostatic charge? No problem, the PG-UNI-II-cable is the correct interface cable. Its metal D-SUB-cases and esd-resistant components you will have here best protection against this influences.

Serial communication to the S5-PLC

Unbenanntes Dokument

You have a PC with programming software and a 9pin COM-port as interface? No problem, for this purpose the PG-UNI-II-cable is exactly the right product. Connect it to PLC and PC and you’re Online. The communication itself is visible by the both included LEDs. Even the 25pin interface of the AS511-card is no problem. You need the NETZ-adapter and also the AG-150-adapter and then this control is programmable, too.

Serial communication with CP and more S5-assemblies

Unbenanntes Dokument
You have a PC with programming software and a 9pin COM-port as interface? No problem, for this purpose the PG-UNI-II-cable is exactly the right product. Connect it to a Siemens assembly such as H1-CP (CP1430), WF470 and PC or CP-525 with the CP525-adapter and PC and you’re Online.
article:
Art. ID.nameprice
9359-2 PG-UNI-II-cable 3m
for PLC's/CP's+ LED + metal case		 99,- €
9359-2.05M PG-UNI-II-cable 5m
for PLC's/CP's+ LED + metal case		 109,- €
9359-2.10M PG-UNI-II-cable 10m
for PLC's/CP's+ LED + metal case		 125,- €

variant:
Art. ID.nameprice
9359-SON Additional charge for special wiring
PG-COM/ PG-UNI/ PG-UNI-II		 5,- €
9390 Additional charge for special length
for S5-Interface cables per Meter 3,- Euro		 3,- €
9359-2.X Special length: PG-UNI-II cable (3m) + 9390 111,- €

accessories:
Art. ID.nameprice
9359-9.M Adapter COM 1 : COM2
25pins (male) - 9pins (female)		 17,- €
9359-9 Adapter COM 1 : COM2
9pins (male) - 25pins (female)		 17,- €
9359-5-150 AG-150-adapter
for PG-UNI + PG-UNI-II-cable to AG-150		 39,- €
9359-5 CP-525-adapter
for PG-UNI + PG-UNI-II-cable <-> CP-525		 39,- €
9359-5K CP-525-K-adapter
for PG-UNI + PG-UNI-II-cable <-> CP-525-communication		 39,- €
9359-4 NETZ-adapter
for PG-UNI-cable /UNI-II-cable/S5-LAN		 59,- €
9359-8 PG-ISO-adapter
1000V galv. seperation		 89,- €
9359-7-II PG-UNI-II - lengthening set
29,- €
9359-MAX233 RS232 / V24 chip
for interfacecable		 5,- €
9359-6 SINUM-adapter
for PG-UNI + PG-UNI-II-cable to SINUMERIK		 39,- €
9359-5-WF470 WF-470-adapter
for PG-UNI + PG-UNI-II-cable to WF470		 39,- €
9310 Additional charge 25-pins PC-plug 10,- €

Shop:PG-ISO-SET - Process Informatik Entwicklungsgesellschaft mbH

PG-ISO-SET

PLC-communication with 1000V galvanic separation without power supply

• galvanic separation between PD/PC and PLC up to 1kV
• contact-protected plastic housing
• supply of the module from the PLC voltage 5V DC and/or 24V DC
• the SET contains a PG-UNI-Kabel (3m) Art.Nr.9359-3 and a PG-ISO-Adapter Art.Nr.9359-8
• slide lock for firm grip on the PLC
Technical Specifications:
Supply voltage: 5V/DV und/oder 24V/DC
Power consumption: 0,3 watt
Display: -
Interfaces:
to the PLC:
TTY/20mA current loop (PG-COM passiv, PLC aktiv)
to the PD/PC:
RS232: 9,6 KBd - 115,2 KBd
Operating temperature: 5 - 55°C
Case: plastic case
Dimensions: PG-UNI: 47 x 40 x 15 mm / PG-ISO-Adapter: 50 x 45 x 15 mm


Galvanic coupling to the S5-PLC (CPU-assemblies 15pin)

Unbenanntes Dokument
You have to configure a galavanic isolated connection to a S5-PLC? No problem, connect the PG-ISO-set (PG-UNI-cable + PG-ISO-adapter) to the PLC and PC, and now you’re Online connected to the PLC. And all without earth-relation between PLC and PC.
article:
Art. ID.nameprice
9359-S PG-ISO-SET 3m 139,- €
9359-S.05M PG-ISO-SET 5m 159,- €
9359-S.10M PG-ISO-SET 10m 179,- €

accessories:
Art. ID.nameprice
9359-9.M Adapter COM 1 : COM2
25pins (male) - 9pins (female)		 17,- €
9359-9 Adapter COM 1 : COM2
9pins (male) - 25pins (female)		 17,- €
9359-5-150 AG-150-adapter
for PG-UNI + PG-UNI-II-cable to AG-150		 39,- €
9359-5 CP-525-adapter
for PG-UNI + PG-UNI-II-cable <-> CP-525		 39,- €
9359-5K CP-525-K-adapter
for PG-UNI + PG-UNI-II-cable <-> CP-525-communication		 39,- €
9359-4 NETZ-adapter
for PG-UNI-cable /UNI-II-cable/S5-LAN		 59,- €
9359-MAX233 RS232 / V24 chip
for interfacecable		 5,- €
9359-6 SINUM-adapter
for PG-UNI + PG-UNI-II-cable to SINUMERIK		 39,- €
9359-5-WF470 WF-470-adapter
for PG-UNI + PG-UNI-II-cable to WF470		 39,- €
9310 Additional charge 25-pins PC-plug 10,- €

Shop:Other interface cables - Process Informatik Entwicklungsgesellschaft mbH

Other interface cables

Other useful devices to simplify your work with the PLC

Your advantage of use PI-interface cables:

• extensive cable and adapter program
in our inventory is a extensive cable and adapter program available for you, even for special connections we have a solution for you
• simple handling
for most interconnections no external power is required
• easy maintenance
our free technical hotline is available with help and advice for you
• function reliability
each cable is manufactured and tested according to quality guidelines in Germany
• function guarantee
each cable is tested with a special cable tester on all connections and connected to PLC to test online features
• CE and EMV reliability
all cables are certified by effective directives

article:
Art. ID.nameprice
9359.1:1 1:1 cable 9pins D-SUB 23,- €
9359.AF Connecting-cable CP with S5-PLC 49,- €
9359.AB PLC-connecting cable
PC <-> Allen-Bradley		 28,- €
9359-90 CP-cable 49,- €
9636-CROSS Cross-cable 3m Cat5+
both sides RJ45-Plug		 10,- €
9359.0 Null-modem-cable 9-pin D-SUB 23,- €
9359.OP OP-Programming cable to PC 3m 49,- €
9636-TCPIP Patch-cable 3m, Cat5+
both sides RJ45-Plug		 10,- €
9359.PCS PCS-cable
for Lauer-operator units		 38,- €
9359-91 PG-685-cable 5m 49,- €
9359.7XX PG-7XX-cable 5m 59,- €
9359-MAX233 RS232 / V24 chip
for interfacecable		 5,- €
9359.M SC-09 cable 3m for Mitsubishi
RS232 <-> RS485		 102,- €
9359-1-RS232 USB-Serial-converter cable 3m
USB <=> RS-232		 125,- €
9359-V24 V24-adapter 51,- €
9380-9S Connecting cable TELE-Book on Slot-PLC
from Siemens		 51,- €
