PI-Service-Mail 319

PI-Service-Mail 319


Nr.: 319
PLC-Communication -Backup -OPC
remote maintenance / remote access ISDN / LTE / internet
TCP & ProfiNet -analysis -diagnosis -monitoring
S5 & S7 & Panel-connection serial / USB / LAN / WIFI
modular analysis- measuring- control- IPC + many sensors
do you still have "old" S5-PLC-controls in operation in your production and they run and run without problems?
There is no need to replace these controls with new ones. "Never touch a running system" who doesn't know the saying?
Nevertheless, you lack a few useful features for more comfort in your production!
New firmware versions:
EtherSens devices
  • FTP-communication with separate history for LTE-transmission revised
  • Timeouts adjusted for web access
WATCHDOG / TINA / TINA-II
  • Integrated data throughput display
  • Configuration expanded by device name
  • Analysis of TCP streams integrated in recordings
  • Bridge from WLAN client to WLAN AP integrated
  • Additional WLAN access point can be used in "Client" mode
  • Fixed an error when activating the "Hide SSID" field
  • Power level display for WLAN channel search expanded
Download links look below!


Networking of your system via LAN-cable
  • Fastest installation in the network of every SIMATIC - S5
  • No complex assembly, just plug it into the PG-interface and communicate
  • S7 compatible
  • Communikation with Fetch/Write
  • PUT/GET with S7-TCP/IP
  • Reading and writing of S5 data (I, Q, M, DB, Z, T) via TCP/IP
  • Ideal for process visualization
  • Programming with STEP 5 via Ethernet
  • Simultaneous programming (multiple PG channels) and visualization possible (integrated multiplexer function)
  • Power supply from the S5 controller or externally
Networking your system via WIFI and/or LAN-cable
  • With integrated WIFI and Ethernet interface in one housing, mobile access to all PLC-systems is no problem
  • The system also functions as an S5 network adapter for programming, remote maintenance and for coupling the different PLC controls
  • Parallel access via LAN/WIFI thanks to the included multiplexer
  • Fastest installation in the network of every SIMATIC - S5
  • No complex assembly, just plug it into the PG-interface and communicate
  • S7 compatible
  • The same range of functions as "networking your system via LAN-cable", only now WIFI and/or LAN




Free PG-interface on the S5-controller
  • All connections and controls on the front
  • Constant checking of device functions and power supply => restart in the event of faults
  • Online immediately with both interfaces to the PLC
  • All PG functions can be carried out by two PGs in parallel
  • Possible controls: S5-90, S5-95, S5-100-series, S5-115 (also CPU945), S5-135U-series and S5-155-series
  • No additional or special adapters are required
  • Connection mechanism, pin assignment and the electrical data correspond to the PG/PLC interfaces of this PLC type
  • Connection options on the PG side: 2 x AS511 (PG-protocole) / 1 x SINEC-L1-bus (no master protocols, no cross traffic) + 1 x AS511
    •
PLC programming cable to USB port
(also for Step5 from Siemens)

  • Complete electronics in the connector housing
  • Sliding lock for a firm hold on the PLC
  • Power supply from the USB interface
  • Extendable up to 100 meters on the PLC side
  • Runs with the standard S5 software despite the virtual COM port
  • Function also with/in VMWare
  • Virtual device driver for Win2000 / XP / Vista / Windows7 / Win 8 / Win 8.1 (32+64-Bit) / Win 10
    •




Simplest PLC-programming-system
for S5/7 also for Win10
  • For the Siemens S5-controls S5-90U - S5-155U
  • For the Siemens S7-controls S7-300/400 [FREEWARE without support]
    ONLINE request for the FREEWARE-license
  • For Windows 98/NT/2000/XP/Vista/Win7/Win8.1/Win10 (32- and 64-Bit)
  • Reads and writes original file formats S5 and S7 from Siemens
  • Simple Windows-interface (switchable to function-key-operation of the old PGs




Solutions/products not only for S5 PLC controls:

Remoteservice without configuration
Networking of S7-200/300/400 controllers with LAN-cable
Networking of S7-200/300/400 controllers with WIFI and/or LAN-cable
S7-200/300/400 control on USB-port of the PC
New firmware versions:
EtherSens firmware version V1.43
WATCHDOG/TINA firmware version V1.10
TINA-II firmware version V1.10
