Downloads • Prospekt • manual • Win-Prommer

• quick access via serial interface
• write, read, delete and compare
• for FlashCards and MMC-Card
• designed for harsh industrial use
• comfortable operation construction Software for Win 95/98/ME/NT/2000/XP with direct Siemens file management
• spacious and robust service bags available as an option

Technical Specifications:
Supply voltage:	24V/DC +/- 20%
Power consumption:	5 watt
Display:	LED for function and watchdog supervision
Handling/Configuration:	WinPrommer-Software
Interfaces:	to the PD/PC: RS232 to any COM-Port others: S5-/S7-FlashCards MMC-Cards (optional)
Operating temperature:	5 - 45°C
Case:	powder coated metal case
Dimensions:	130 x 80x 50mm

to the order datas

article:
Art. ID.	name	price		quantity
9363-8	FLASH-PROMMER-II 24VDC for Flashcards	404,- €
9363-8-MMC	FLASH-PROMMER-II-MMC 24VDC for Flashcards + MMC	499,- €
9363-8-USB	FLASH-PROMMER-USB	599,- €

to the order datas

accessories:
Art. ID.	name	price		quantity
9359.1:1	1:1 cable 9pins D-SUB	23,- €
9391.1	24V DC power-supply unit 625mA Primary 110V - 240 VAC Euro+USA-plug	39,- €
9363-6	Servicebag MINI-PROMMER + FLASH-PROMMER	33,- €
9372-24	Power connector 3pins big	2,- €
