MPI / PPI - Profibusmodem
Programming of S7-PLC’s via telephone from afar
- Standard modem-protocol, the Siemens TS-software is needed
- Analogue modem for world wide use
- Data transmission via radio (GSM)
- Screwable antenna/prolongable (GSM)
- For Siemens-S7-Teleservice
- Incl. modem-cable and S7-cable (1m)
- GSM-Modem incl. magnetic base antenna and S7-cable (1m)
| Technical Specifications: | |
| Supply voltage: | 24V/DC +/- 20% |
| Power consumption: | 5 watt |
| Display: | expressive LCD-display 4 status-LEDs |
| Handling/Configuration: | integrated keypad |
| Interfaces: |
to the PLC:
PPI/MPI/Profibus interface: 9,6 KBd - 12 MBdto the PD/PC:
RS232: 9,6 KBd - 115,2 KBd / with a 1on1-cable to the PCothers:
- |
| Integrated modem: | 33K6-analogue modem GSM-modem |
| Operating temperature: | 5 - 55°C |
| Case: | powder coated metal case with mounting flange |
| Dimensions: | 165 x 90 x 50 mm |
Remote maintenance / telecontrol of PLC  The access to the connected PLC with the Siemens TS-software
or PG-2000 including TS-option results of coupling via Analogue-, ISDN- (only
with AB-adapter) as well as GSM-line.
| Use on-site without PC-adapter?  With the MPI/PPI/Profibus-modem you can connect serial to
your PC/laptop and then communicate directly with the PLC without a PC-adapter
or other S7-programming cables.
|
to the order datas
| article: | |||||
|---|---|---|---|---|---|
| Art. ID. | name | price | quantity | ||
| 9379-OP | MPI/PPI-Modem maximum baud rate MPI- and Profibus up to 12Mbaud |
469,- € |   |
||
| 9379-G-OP | MPI/PPI-Modem GSM maximum baud rate MPI- and Profibus up to 12Mbaud |
619,- € | |
||
to the order datas
| accessories: | |||||
|---|---|---|---|---|---|
| Art. ID. | name | price | quantity | ||
| 9359.1:1 | 1:1 cable 9pins D-SUB D-SUB 9pins (male) <=> D-Sub 9pins (female), 1to1-assignment |
23,- € | |
||
| 9391.1 | 24V DC power-supply unit 625mA Primary 110V - 240 VAC Euro+USA-plug |
39,- € | |
||
| 9370-ISDN | ISDN-adapter for analogue terminals full ISDN-functionality e.g. call waiting, 3-way conferencing, broker's call |
251,- € | |
||
| 9379-ANT | Magnetic base antenna for TP, TS + MPI-Modem |
24,- € | |
||
| 9379.1 | MPI-/Profibus connecting cable 1m connects MPI-modem/TP-II with the S7-PLC |
10,- € | |
||
| 9372-24 | Power connector 3pins big connector plug lockable by jack with screws |
3,- € | |
||
| 9370-TAE | TAE junction box analogue telephone box (NFN) for on-wall mounting |
20,- € | |
||
| 9370-SET | Phone-connector-set 16parts worldwide use |
230,- € | |
||
| 9370-8-D/USA | Phone-cable analogue Germany+USA RJ12 plug <=> RJ12 plug with TAE-adapter for Germany |
10,- € | |
||
| 9370-8-BE | Special phone-cable for Belgium RJ12 plug <=> telephone plug of Belgium |
23,- € | |
||
| 9370-8-DK | Special phone-cable for Denmark RJ12 plug <=> telephone plug of Denmark |
23,- € | |
||
| 9370-8-FR | Special phone-cable for France RJ12 plug <=> telephone plug of France |
23,- € | |
||
| 9370-8-GB | Special phone-cable for Great Britain RJ12 plug <=> telephone plug of Great Britain |
23,- € | |
||
| 9370-8-NL | Special phone-cable for Netherlands RJ12 plug <=> telephone plug of the Netherlands |
23,- € | |
||
| 9370-8-CH | Special phone-cable for Switzerland RJ12 plug <=> telephone plug of Switzerland |
23,- € | |
||
| 9370-8-AT | Special phone-cable for Austria RJ12 plug <=> telephone plug of Austria |
23,- € | |
||
