PG-ISO-adapter
galvanic separation up to 1000V
- Contact-protected plastic case
- Generates new current sources and a ne ground for the communication
- Galvanic separation between PC and PLC up to 1000V
- Power supply from the PLC
| Technical Specifications: | |
| Supply voltage: | 5V/DC and/or 24V/DC +/- 20% |
| Power consumption: | 1 watt |
| Interfaces: |
2 x TTY/20mA current loop (1 x 15pol plug / 1 x 15pol jack) |
| Galvanic separation: | 1000V PLC to the PC |
| Operating temperature: | 5 - 55°C |
| Case: | plastic case |
| Dimensions: | 50 x 45 x 15 mm |
to the order datas
| article: | |||||
|---|---|---|---|---|---|
| Art. ID. | name | price | quantity | ||
| 9359-8 | PG-ISO-adapter 1000V galv. seperation |
89,- € |   |
||
