WLAN-terminal - Process Informatik Entwicklungsgesellschaft mbH

WLAN-terminal


Successor: ALF-UA high-speed WIFI-Router for Din-Rail-mounting (Art.No: 9352-ALF-UA)

Connecting your ethernet-participants direct to your WLAN-network

connection of a network client via WLAN
to an Access-Point or in AdHoc-mode
USB-drivers for parameterization only for Win XP!

  • Suitable for DIN-rail EN 60715 TH35 and wall-mounting
  • For S7-1200, S5-LAN++, S7-LAN and Ethernet-CPs usable
  • Connecting a direct connected network subscriber (not over switch) via WLAN to an Access Point
  • Ad-hoc capable for direct programming with the laptop
  • Auto-negotiation of the RJ45-Ethernet jack

more...

ARTNR: 9352-WLAN-KLEMME
WLAN-terminal
Obsolete
EAN number: 4260363241557
HS-code: 85444290
Weight: 0.1 kg



Wöhrle Belgium B.V.B.A.
Mechelen , Belgium
www.wohrle.be
  • Suitable for DIN-rail EN 60715 TH35 and wall-mounting
  • For S7-1200, S5-LAN++, S7-LAN and Ethernet-CPs usable
  • Connecting a direct connected network subscriber (not over switch) via WLAN to an Access Point
  • Ad-hoc capable for direct programming with the laptop
  • Auto-negotiation of the RJ45-Ethernet jack
  • Power supply 24V DC over spring clip; while configuration from USB of the connected PC
  • Spring clips for conductors with max. 2.5 mm² and eyelets, terminals and tabs
  • Simply parameterizing via USB, driver for Win XP available
  • CE / EMC compliant design
  • Used plastic complies UL 94 V-0
Universal transfer of LAN-products into WLAN
Produkbild
You have a variety of LAN products and would like to communicate to them via WLAN? No problem, with the WLAN-Klemme you will be able to contact all these products.
Supply voltage: 24V DC +/- 20%
5V DC USB
Power consumption: 1,2 watt
Display: 2 status-LEDs
Handling/Configuration: S7BridgeConfig-software
Interfaces:
to the PLC:
10/100BaseTX RJ45-ethernetplug
to the PD/PC:
WLAN connection (802.11 b/g)
Mini-USB-B-jack (for Configuration)
Operating temperature: 0 - 55°C
Case: plastic case UL 94 V-0
Dimensions: 90 x 59 x 18 mm
All prices plus costs of delivery, shipping insurance and VAT.

accessories:

9391.1
24V DC power-supply unit 625mA

Primary 110V - 240 VAC Euro+USA-plug
Quickbestellung INFOMAIL
by e-mail
59,00 €
plus VAT. and shipping


9636-TCPIP.02M
Patch-cable 0.25m, Cat5e, shielded

RJ45 plug <=> RJ45 plug, 1:1
Quickbestellung INFOMAIL
by e-mail
15,00 €
plus VAT. and shipping


9352-WLAN-ANT
Magnetic base antenna

for S7-WLAN-Bridge, WLAN-Klemme, EtherSens cable length: 3m
Quickbestellung INFOMAIL
by e-mail
83,00 €
plus VAT. and shipping


9350-9-CHP-24V-OUT
CheapConn Busconnector with 24V-output

Comfortable power supply for ALF, TONI, WLAN-Klemme and CONNECT-ROUTER
Quickbestellung INFOMAIL
by e-mail
85,00 €
plus VAT. and shipping


All prices plus costs of delivery, shipping insurance and VAT.
