ProfiNet - analysis/burglary/failure/life-cycle
table-case
desktop-case
Features:- Non-reactive recording of Ethernet communication
- Secure and passive decoupling of telegrams
- Monitors all OSI layers starting from layer 2 and monitors packets of all sizes and types and VLAN traffic
- For 10 or 100Mbit/s
- To monitoring-PC with WIFI 2,4 GHz
more...
ARTNR: 7051
ProfiNet - analysis/burglary/failure/life-cycle
| EAN number: | 4260363249140 | |
| HS-code: | 85176200 | |
| Weight: | 0.3 kg |
Alternativen
plus VAT. and shipping
plus VAT. and shipping
ProfiNet - analysis/burglary/failure/life-cycle
for Din-rail-mounting with 3rd LAN-port
by e-mail
plus VAT. and shipping
plus VAT. and shipping
- Non-reactive recording of Ethernet communication
- Secure and passive decoupling of telegrams
- Monitors all OSI layers starting from layer 2 and monitors packets of all sizes and types and VLAN traffic
- For 10 or 100Mbit/s
- To monitoring-PC with WIFI 2,4 GHz
- No influence on Ethernet transmission in case of power failure
- No influence on the ProfiNet-system/-timing (real-time behavior)
- No security risks
- Exact timestamps
- Plug directly into the ProfiNet cable
- Installation in less than 1 minute
- No Switch needed
- Invisible to switch/devices
- Logging error-protocols
- Analysis of the participants, bus overview
- Determination of the probability of default of participants
- Activity-documentation
- Automatic detection of every PN-network
- Monitoring (e-mail-message)
- Burglary
- Unauthorized PN-participants
- Malfunction
- Failure/missing PN-participants
- Abnormalities
- Creeping disorder
- Extendable with 3rd LAN-socket for connection of recording-PC via LAN-cable, if WiFi is not permitted/possible
Exact analysis of your Profinet members.
Addresses, configurations and other data can be recorded directly.
See immediately possible conflicts due to the configuration.
Identify devices that are likely to fail in the near future.
Detect defective devices that no longer respond to PN protocols.
Defective devices are reported by email and logged.
No long troubleshooting thanks to exact station information.
Detection and logging of unauthorized access in the defined Profinet
Attempted break-ins and access to the network are recognized immediately and e.g. reported by email
Logging of all accesses in the network for historical processing
Possible data-storage USB-stick or FTP-server via USB-network-stick.
Detection and logging of unauthorized access in the defined Profinet
Attempted break-ins and access to the network are recognized immediately and e.g. reported by email
Logging of all accesses in the network for historical processing
Possible data-storage USB-stick or FTP-server via USB-network-stick.
Recognize cable breakage, contact problems and line faults.
Retransmissions and failures are logged and reported.
Early acting before total failure of the participant.
Recognize cable breakage, contact problems and line faults.
Retransmissions and failures are logged and reported.
Early acting before total failure of the participant.
Identify impending failures in your Profinet.
Creeping aging will be displayed to you very detailed.
The Profinet-Watchdog give you the change to react before something happens.
Identify impending failures in your Profinet.
Creeping aging will be displayed to you very detailed.
The Profinet-Watchdog give you the change to react before something happens.
Detect intrusions and anomalies on your ProfiNet.
Early detection of malfunction and failures and malfunctions.
Easy installation, plug and play double socket.
Detect intrusions and anomalies on your ProfiNet.
Early detection of malfunction and failures and malfunctions.
Easy installation, plug and play double socket.
| Supply voltage: |
24V DC +/- 20% USB (from PC/power-pack) |
| Power consumption: | 2 watt |
| Display: |
WEB-Browser status LEDs |
| Handling/Configuration: | WEB-Browser |
| Interfaces: |
2 x 10/100BaseTX RJ45-ethernet-plug Antenna-connector SMA(f) (2.4 GHz IEEE 802.11b/g) |
| Operating temperature: | 0 - 55°C |
| Case: | ABS-plastic case V0 |
| Dimensions: | 115 x 95 x 30 mm |
| Scope of delivery: |
ProfiNet-WATCHDOG (table-case) WIFI-stub-antenna small power plug |
