L1-Controller

Interface converter for connecting different interface types

for 5VDC without plug-in module, configuration
locked in the flash memory

Computers have an optional possibility of attendance, as Master or Slave, on Sinec-L1-bus
The interfaces of the L1 controllers are with plug-in modules (RS232, RS422, TTY, L1-bus) customizable
Easy data exchange with the L1-Bus-Controller via ASCII protocol
Autarkic implementation of the controller’s L1-Bus functions, also without computer performance
Settings for diverse baud rates and modes

more...

variants:

754,00 € plus VAT. and shipping

ARTNR: 9510-F
L1-BUS Controller DIN-rail-holder Flash-version
Obsolete

EAN number:		4260363242165
HS-code:		85389099

Computers have an optional possibility of attendance, as Master or Slave, on Sinec-L1-bus
The interfaces of the L1 controllers are with plug-in modules (RS232, RS422, TTY, L1-bus) customizable
Easy data exchange with the L1-Bus-Controller via ASCII protocol
Autarkic implementation of the controller’s L1-Bus functions, also without computer performance
Settings for diverse baud rates and modes
Status display for preset modes, errors and specifications

Sinec-L1-bus without master (CP530)
Produkbild

You have a running Sinec-L1-bus and your master the CP530 is defective or rather broke down and the bus has to continue running? No problem, connect the L1-controller to the according bus-modules instead of the CP530, define the circulation list of the clients and the L1-bus continues running immediately.


Supply voltage:	5V DC +/- 20%
Power consumption:	-
Display:	2 x 7-segment display
Handling/Configuration:	DIP-Switch
Interfaces:	others: 1 x D-Sub-female 9pol for PC connection 3 x Weidmüller for 5V DC power supply 9 x Weidmüller for bus connection A and B
Operating temperature:	0 - 55°C
Case:	plastic case
Dimensions:	160 x 100 x 50 mm

Scope of delivery:	L1-Controller
